FLUKE 1623-2

About FLUKE 1623-2

GeneralDisplay:1999 digit LCD Display with special symbols, digit height 25 mmUser interface Instant measurement through TURN and START one button concept. The only operating elementsare rotary switch and START buttonRobust, water and dust resistant Instrument is designed for tough environmental conditions (rubber protective cover, IP56)Memory Internal memory storage up to 1500 records accessible via USB portTemperature rangesOperating temperature -10 C to 50 C (14 F to 122 F)Storage temperature -30 C to +60 C (-22 F to +140 F)Temperature coefficient ï 0.1 % of reading/C <18 C >28 CIntrinsic error Refers to the reference temperature range and is guaranteed for 1 yearOperating error Refers to the operating temperature range and is guaranteed for 1 yearClimatic class C1 (IEC 654-1), -5 C to +45 C (23 to +115 F), 5 % to 95 % RHProtective type IP56 for case, IP40 for battery door according to EN60529Safety Protection by double and/or reinforced insulation. max. 50 V to earth. IEC61010-1: CAT none,Pollution degree 2EMC (Emission Immunity) IEC61326-1: PortableQuality system Developed, designed and manufactured according to DIN ISO 9001External voltage V ext, max = 24 V (dc, ac < 400 Hz), measurement inhibited for higher valuesV ext rejection > 120 dB (162ïï3, 50, 60, 400 Hz)Measuring time Typical 6 sec.Max. overload 250 V rms (pertains to misuse)Auxiliary power 6 x 1.5 V alkaline (type AA LR6)Battery life span Typical > 3,000 measurementsDimensions (WxHxD) 250 mm x 133 mm x 187 mm (9.75 in x 5.25 in x 7.35 in)Weight 1.1 kg (2.43 lb) including batteries7.6 kg (16.8 lb) including accessories and batteries in carrying caseRA 3-pole ground resistance measurement (IEC 1557-5)Switch position Resolution Measuring range Accuracy Ope
